Description
Three Lighting Moods at the Push of a Button – Thanks to the CCT Switch
Say goodbye to fixed colour temperatures! Before installing the downlight, simply set your preferred ambiance using the built-in selector switch: 3000 K for a warm, cosy atmosphere, 4000 K for neutral task lighting, or 6000 K for a crisp, daylight-bright look. One model – three possibilities, with no additional controllers or complex wiring required.
Your Advantages at a Glance
Adjustable Cutout Width The sliding mechanism covers openings from Ø 65 to 155 mm – ideal for renovations or varying ceiling conditions. |
Ultra-Flat Design Only 19 mm deep – fits into shallow ceiling voids or wherever ducts and pipes restrict space. |
CCT Colour Switch Choose 3000 / 4000 / 6000 K directly on the housing – one luminaire for any atmosphere. |
1000 Lumens – Bright & Glare-Free The opal diffuser distributes light evenly across a 120° beam angle – no flicker, no spot effect. |
Integrated Driver No external driver needed – simply connect to 230 V and you're done. |
Low Energy Costs Only 12 kWh per 1000 hours – gentle on your electricity bill in the long run. |
Choose Your Colour Temperature – Here’s How Simple It Is
Before installation, set the small switch on the housing to your desired colour temperature:
| 3000 K Warm White – Perfect for living rooms, bedrooms, and cosy areas. | |
| 4000 K Neutral White – Ideal for kitchens, offices, and all work surfaces. | |
| 6000 K Cool White – Delivers maximum brightness in bathrooms, workshops, or corridors. |
Technical Specifications
| Property | Value |
| Rated Power | 12 W |
| Rated Voltage | 220–240 V AC |
| Luminous Flux | 1000 lm |
| Luminous Efficacy | 83 lm/W |
| Beam Angle | 120° |
| Colour Rendering (CRI) | > 80 (Ra) |
| Colour Temperature (CCT) | 3000 / 4000 / 6000 K (switchable) |
| Energy Efficiency Class | G (EU 2019/2015, Scale A–G) |
| Energy Consumption | 12 kWh / 1000 h |
| Power Factor | > 0.90 |
| Ingress Protection | IP20 |
| Lifespan | 30,000 h (L90 / Tc=55°C) |
| Operating Temperature | -20 °C to +50 °C |
| Housing Material | PVC, White |
| Dimmable | No |
| Driver | Integrated |
| Outer Dimensions (ØxH) | 220 x 32 mm (visible rim: Ø 170 mm) |
| Recess Depth | 19 mm |
| Cutout (Adjustable) | Ø 65 – 155 mm (stepless via sliding mechanism) |
| Weight | 0.35 kg |
| Certifications | ISO9001, ISO14001, CE, RoHS |
Installation: Flexible, Fast, and Safe
Thanks to the clever sliding mechanism, this recessed downlight completely covers existing holes between 65 and 155 mm – there’s no need to drill a millimetre-perfect cutout. Simply insert the luminaire into the opening, secure it with the spring clips, and connect it directly to 230 V. The integrated driver makes external power supplies unnecessary. Please note: Installation must only be carried out by qualified personnel and with the power supply disconnected.
Application Areas – Wherever Flat and Flexible Are Essential
The combination of extreme flatness and an adjustable cutout makes this LED downlight a versatile all-rounder for both renovation and new construction. It works brilliantly as wide-area ceiling lighting in hotels, restaurants, and retail stores, meets the highest demands in offices and medical practices, and also adds stylish accents in residential spaces, hallways, and bathrooms (IP20, therefore outside splash-water zones). The unobtrusive white PVC housing blends seamlessly into any ceiling.
Why This Recessed Downlight Stands Out
Bring maximum flexibility to your lighting: The switchable colour temperature saves you from stocking multiple variants, the adjustable cutout width eliminates the need for time-consuming re-drilling, and the extremely flat design fits even in ceilings with minimal void space. With a consumption of only 12 kWh per 1000 hours, the downlight works efficiently and impresses with a solid lifespan of 30,000 hours. Choose a reliable recessed downlight that will give you long-term enjoyment with its simple installation and outstanding versatility.
Frequently Asked Questions About the LED Eco Downlight
On the back of the luminaire, you'll find two sliding spring clips. You can adjust them steplessly from 65 mm to 155 mm. This allows the downlight to fit into pre-existing ceiling openings – perfect when replacing old recessed lights.
The CCT switch is located on the housing and is easily accessible before mounting. To change the colour temperature after installation, simply remove the downlight briefly – the spring clips make this a matter of seconds.
No, this model is not dimmable. In return, the integrated driver and simple 230 V direct connection give you a particularly straightforward and affordable solution.
The white plastic housing is lightweight, corrosion-free, and contributes to the low total weight of just 0.35 kg. It is designed for indoor use (IP20) and stays dimensionally stable even after years of service.
