Description
Three Lighting Moods - Easily Selectable via CCT Switch
You define the atmosphere of your rooms. Before installation, set the desired colour temperature on the downlight's housing: 3000 K creates a warm, inviting ambiance, 4000 K provides neutral task lighting, and 6000 K produces a daylight-bright, activating room feeling. One model - three possibilities, with no extra components or complex wiring required.
Your Advantages at a Glance
Compact & Versatile Only 115 mm outer diameter and 0.2 kg - ideal for hallways, small rooms, or row installation. |
Proven Standard Cutout Designed for ceiling openings of 100-110 mm - perfect for cleanly replacing old halogen recessed installations. |
CCT Colour Switch Choose 3000 / 4000 / 6000 K directly on the housing - one luminaire, three colour temperatures. |
Integrated Driver No external driver needed - simply connect to 230 V, snap in, done. |
Pleasant Room Lighting The opal diffuser distributes light evenly across a 120° angle - no flickering, no glare. |
Economical Consumption Only 6 kWh per 1000 operating hours - minimal electricity costs with solid brightness. |
How to Choose Your Preferred Colour
Before installation, set the small switch on the housing to your desired colour temperature:
| 3000 K Warm White - Cosy light for living rooms, bedrooms, and hallways. | |
| 4000 K Neutral White - Promotes concentration in kitchens, work nooks, and offices. | |
| 6000 K Cool White - Activating and bright for bathrooms, utility rooms, and basements. |
Technical Specifications
| Property | Value |
| Rated Power | 6 W |
| Rated Voltage | 220-240 V AC |
| Luminous Flux | 500 lm |
| Luminous Efficacy | 83 lm/W |
| Beam Angle | 120° |
| Colour Rendering (CRI) | > 80 (Ra) |
| Colour Temperature (CCT) | 3000 / 4000 / 6000 K (switchable) |
| Energy Efficiency Class | G (EU 2019/2015, Scale A-G) |
| Energy Consumption | 6 kWh / 1000 h |
| Power Factor | > 0.90 |
| Ingress Protection | IP20 |
| Lifespan | 30,000 h (L90 / Tc=55°C) |
| Operating Temperature | -20 °C to +50 °C |
| Housing Material | PVC, White |
| Dimmable | No |
| Driver | Integrated |
| Outer Dimensions (ØxH) | 115 x 32 mm |
| Recess Depth | 32 mm |
| Cutout | Ø 100 - 110 mm |
| Weight | 0.20 kg |
| Certifications | ISO9001, ISO14001, CE, RoHS |
Installation - Quick, Clean, and Safe
This recessed downlight is designed for hassle-free replacement. Drill a cutout with a diameter of 100 to 110 mm, insert the luminaire, and secure it with the spring clips. The connection is made directly to 230 V - no external driver required. Please ensure installation is carried out exclusively by qualified personnel and with the power supply switched off beforehand.
Application Areas - The Compact Choice for Many Spaces
With its handy format and 500 lumens, this LED downlight is perfect for hallways, corridors, small bathrooms (IP20, therefore outside splash-water zones), or as atmospheric supplementary lighting in living rooms and bedrooms. In commercial settings - such as hotel rooms, meeting nooks, or as row installations in retail stores - it provides uniform, glare-free illumination. The simple white PVC housing blends discreetly into any ceiling, and the classic cutout enables a quick 1:1 replacement of old recessed lights.
Why This Recessed Downlight Stands Out
You get a well-thought-out mini solution for atmospheric lighting: 500 lumens for pleasant room brightness, three selectable colour temperatures, an integrated driver for direct 230 V wiring, and a solid lifespan of 30,000 hours. At just 0.20 kg, the luminaire is particularly lightweight and easy to install. The proven standard cutout ensures a quick replacement, and the glare-free opal diffuser creates a cosy light atmosphere without annoying reflections. Choose a compact, energy-saving luminaire that installs in no time and bathes your rooms in pleasant light.
Frequently Asked Questions About the LED Eco Downlight 6 W
The downlight fits ceiling openings with a diameter of 100 to 110 mm. This is a common size that often allows you to replace old halogen recessed lights without reworking the ceiling.
The CCT selector switch is located on the back of the housing. If you wish to change the colour after mounting, simply remove the downlight briefly, flip the switch, and reinsert it - it takes just seconds.
No, this model does not support dimming. In return, you get a particularly simple and robust solution with an integrated driver and direct 230 V connection.
With 500 lumens per luminaire, this model is particularly suited for smaller rooms or supplementary lighting. As a rule of thumb, plan one luminaire per 6-8 m². For uniform illumination, we recommend spacing the luminaires about 1.0 to 1.2 m apart.
